Solar Panel Polycrystalline 340 Wp

0 0 reviews

General rating

0,0 /5

Latest review

L. Dupont

Review posted on 25 Juin 2025 by a user.

Unbeatable value for money

Quick installation, perfect design, discreet, easy to program, worked immediately. I recommend...

See all reviews
Laboratory
  • SOLAR PANEL 340 WATTS |
  • Polycrystalline |
  • 72 Cells PV Module |
  • Power tolerance 3/+3W |
  • L 1970 mm, W 990 mm, D 40 mm |
  • 22.00 kg |
  • Material Warranty 15 years |
  • Linear Power Warranty 25 years |
  • Efficiency 17.1%
Best price per Watt : 0.17 Per panel : 57.46

Brand : N/A

Globe http://www.rhinesolar.in/

Place 417, EPIP, Phase-III Kundli Industrial Estate, Sonepat, Haryana-131028

user icon
location icon
calendar icon
installer icon
material icon
note icon
Free comments

Reply

Product image
Users 3218

Users (3218)

Installers 37

Installers (37)

Manufacturer 24
Distributors 56

Distributors (56)

Main suppliers

SOLARDROP
Payment WIMSE COIN, Credit card, Bank transfer
Per Watt : $0.12
View offer
WATT-U-NEED
Payment Credit card, Bank transfer
Per Watt : $0.14
View offer

Reviews

0 reviews

0,0/5
0
0
0
0
0
See all reviews

Laboratory

Technical rating

Lab Icon
See the test

Advice

Lorem ipsum dolor sit amet...

Read more

Characteristics

  • Panel power 340 Wp
  • Panel category Standard Panel
  • Efficiency 17.1%
  • Cell type Polycrystalline
  • Linear power output warranty 25 years
  • Standard warranty 15 years
  • Number of cells 72
  • Weight 22 kg
See all characteristics

General characteristics

Solar cells
Polycrystalline
Panel type
Framed
Model designation
RS-PM-340WP
Number of cells
72

Dimensions and weight

Dimension
Length 1970 mm
Width 990 mm
Depth 40 mm
Weight
22 kg
Panel area
1.95 m²

Mechanical characteristics

Glass thickness
3.2 mm
Frame type
Framed
Frame material
Anodized aluminum
Frame color
Silver
Junction box (diodes)
3 diodes
Output cable
N/A
Connector
MC4

Warranty

Material warranty
15 yrs
Linear power warranty
25 yrs
Power output

Higher lifetime electrical yield

First-year degradation
N/A
Linear degradation per year
N/A

ELECTRICAL DATA AT STC

Standard Test Conditions

Irradiance 1000W/m², cell temperature 25°C & AM1.5

Maximum output power (Pmax)
340 Wp
Maximum power voltage (Vmp)
39.02 V
Current at Pmax (Imp)
8.72 A
Open-circuit voltage (Voc)
46.51 V
Short-circuit current (Isc)
9.36 A
Module efficiency
17.1 %
Power tolerance
3/+3 W

ELECTRICAL DATA AT NOCT

Nominal Operating Cell Temperature:

Irradiance 800W/m², ambient 20°C, wind 1m/s

Maximum output power (Pmax)
N/A
Maximum power voltage (Vmp)
N/A
Current at Pmax (Imp)
N/A
Open-circuit voltage (Voc)
N/A
Short-circuit current (Isc)
N/A

TEMPERATURE COEFFICIENTS

NOCT
N/A
Temp. coeff. of Pmax
-0.38 %/˚C
Temp. coeff. of Voc
-0.29 %/˚C
Temp. coeff. of Isc
+0.05 %/˚C

MAXIMUM RATINGS

Maximum system voltage (IEC)
1000 V
Maximum system voltage (UL)
N/A
Max. series fuse
20 A
Operating temperature range
40 ˚C ~ 80 ˚C
Maximum front load (snow)
N/A
Maximum back load (wind)
N/A

Aucun documents disponible

No technical drawing available

No packaging photos available
