Characteristics

  • Panel power 550 Wp
  • Panel category Half-Cut Panel
  • Efficiency 21%
  • Cell type Monocrystalline PERC
  • Linear power output warranty 25 years
  • Standard warranty 10 years
  • Number of cells 144
  • Weight 27.9 kg
See all characteristics

General characteristics

Solar cells
Monocrystalline PERC
Panel type
Framed
Model designation
RS-MC-HC-550WP
Number of cells
144

Dimensions and weight

Dimension
Length 2278 mm
Width 1134 mm
Depth 35 mm
Weight
27.9 kg
Panel area
2.58 m²

Mechanical characteristics

Glass thickness
3.2 mm
Frame type
Framed
Frame material
Anodized aluminum
Frame color
Silver
Junction box (diodes)
3 diodes
Output cable
Ø 4 mm² / 1500 mm
Connector
MC4

Warranty

Material warranty
10 yrs
Linear power warranty
25 yrs
Power output

Higher lifetime electrical yield

First-year degradation
N/A
Linear degradation per year
N/A

ELECTRICAL DATA AT STC

Standard Test Conditions

Irradiance 1000W/m², cell temperature 25°C & AM1.5

Maximum output power (Pmax)
550 Wp
Maximum power voltage (Vmp)
44.21 V
Current at Pmax (Imp)
12.45 A
Open-circuit voltage (Voc)
49.68 V
Short-circuit current (Isc)
13.46 A
Module efficiency
21 %
Power tolerance
3/+3 W

ELECTRICAL DATA AT NOCT

Nominal Operating Cell Temperature:

Irradiance 800W/m², ambient 20°C, wind 1m/s

Maximum output power (Pmax)
N/A
Maximum power voltage (Vmp)
N/A
Current at Pmax (Imp)
N/A
Open-circuit voltage (Voc)
N/A
Short-circuit current (Isc)
N/A

TEMPERATURE COEFFICIENTS

NOCT
45 ± 2˚C
Temp. coeff. of Pmax
-0.38 %/˚C
Temp. coeff. of Voc
-0.3 %/˚C
Temp. coeff. of Isc
+0.06 %/˚C

MAXIMUM RATINGS

Maximum system voltage (IEC)
1500 V
Maximum system voltage (UL)
N/A
Max. series fuse
25 A
Operating temperature range
40 ˚C ~ 80 ˚C
Maximum front load (snow)
N/A
Maximum back load (wind)
N/A
