Solar Panel Half-cut Monocrystalline PERC 350 Wp

0 0 reviews

General rating

0,0 /5

Latest review

L. Dupont

Review posted on 25 Juin 2025 by a user.

Unbeatable value for money

Quick installation, perfect design, discreet, easy to program, worked immediately. I recommend...

See all reviews
Laboratory
  • SOLAR PANEL 350 WATTS |
  • NE SOLAR |
  • Half-cut |
  • Monocrystalline PERC |
  • 120 Cells PV Module |
  • Grade A |
  • Power tolerance 0/+3W |
  • L 1755 mm, W 1038 mm, D 35 mm |
  • 20.00 kg |
  • Material Warranty 10 years |
  • Linear Power Warranty 25 years |
  • Efficiency 19.2%
Best price per Watt : 0.25 Per panel : 88.89

Brand : NE SOLAR

Globe #

Place Blvd. 3rd Makedonska Brigada 54

user icon
location icon
calendar icon
installer icon
material icon
note icon
Free comments

Reply

Product image
Users 3218

Users (3218)

Installers 37

Installers (37)

Manufacturer 24
Distributors 56

Distributors (56)

Main suppliers

SOLARDROP
Payment WIMSE COIN, Credit card, Bank transfer
Per Watt : $0.12
View offer
WATT-U-NEED
Payment Credit card, Bank transfer
Per Watt : $0.14
View offer

Reviews

0 reviews

0,0/5
0
0
0
0
0
See all reviews

Laboratory

Technical rating

Lab Icon
See the test

Advice

Lorem ipsum dolor sit amet...

Read more

Characteristics

  • Panel power 350 Wp
  • Panel category Half-Cut Panel
  • Efficiency 19.2%
  • Cell type Monocrystalline PERC
  • Linear power output warranty 25 years
  • Standard warranty 10 years
  • Number of cells 120
  • Weight 20 kg
See all characteristics

General characteristics

Solar cells
Monocrystalline PERC
Panel type
Framed
Model designation
NESE 350-60MH
Number of cells
120

Dimensions and weight

Dimension
Length 1755 mm
Width 1038 mm
Depth 35 mm
Weight
20 kg
Panel area
1.82 m²

Mechanical characteristics

Glass thickness
3.2 mm
Frame type
Framed
Frame material
Anodized aluminum
Frame color
N/A
Junction box (diodes)
3 diodes
Output cable
Ø 4 mm² / 1200 mm
Connector
MC4

Warranty

Material warranty
10 yrs
Linear power warranty
25 yrs
Power output
10 year(s); 92.5 %
25 years; 84.3 %

Higher lifetime electrical yield

First-year degradation
2.5 %
Linear degradation per year
0.5 %

ELECTRICAL DATA AT STC

Standard Test Conditions

Irradiance 1000W/m², cell temperature 25°C & AM1.5

Maximum output power (Pmax)
350 Wp
Maximum power voltage (Vmp)
33.4 V
Current at Pmax (Imp)
10.48 A
Open-circuit voltage (Voc)
40.2 V
Short-circuit current (Isc)
8.92 A
Module efficiency
19.2 %
Power tolerance
0/+3 W

ELECTRICAL DATA AT NOCT

Nominal Operating Cell Temperature:

Irradiance 800W/m², ambient 20°C, wind 1m/s

Maximum output power (Pmax)
256 W
Maximum power voltage (Vmp)
30.9 V
Current at Pmax (Imp)
8.28 A
Open-circuit voltage (Voc)
37.2 V
Short-circuit current (Isc)
N/A

TEMPERATURE COEFFICIENTS

NOCT
44 ± 3˚C
Temp. coeff. of Pmax
-0.36 %/˚C
Temp. coeff. of Voc
-29 %/˚C
Temp. coeff. of Isc
+0.05 %/˚C

MAXIMUM RATINGS

Maximum system voltage (IEC)
1500 V
Maximum system voltage (UL)
1000 V
Max. series fuse
20 A
Operating temperature range
40 ˚C ~ 85 ˚C
Maximum front load (snow)
5400 Pa
Maximum back load (wind)
2400 Pa

Aucun documents disponible

No technical drawing available
