Solar Panel Bifacial Half-cut N-Type TOPCon 425 Wp

0 0 reviews

General rating

0,0 /5

Latest review

L. Dupont

Review posted on 25 Juin 2025 by a user.

Unbeatable value for money

Quick installation, perfect design, discreet, easy to program, worked immediately. I recommend...

See all reviews
Laboratory
  • SOLAR PANEL 425 WATTS |
  • JUSTSOLAR |
  • Bifacial Half-cut |
  • N-Type TOPCon |
  • 108 Cells PV Module |
  • Power tolerance 0/+5W |
  • L 1722 mm, W 1134 mm, D 30 mm |
  • 23.70 kg |
  • Material Warranty 12 years |
  • Linear Power Warranty 30 years |
  • Efficiency 21.8%
Best price per Watt : 0.20 Per panel : 84.00

Brand : JUSTSOLAR

Globe https://www.jusolar.com/

Place 1288 Kanghe Road, Jiaxing City, Zhejiang Province, China

user icon
location icon
calendar icon
installer icon
material icon
note icon
Free comments

Reply

Product image
Users 3218

Users (3218)

Installers 37

Installers (37)

Manufacturer 24
Distributors 56

Distributors (56)

Main suppliers

SOLARDROP
Payment WIMSE COIN, Credit card, Bank transfer
Per Watt : $0.12
View offer
WATT-U-NEED
Payment Credit card, Bank transfer
Per Watt : $0.14
View offer

Reviews

0 reviews

0,0/5
0
0
0
0
0
See all reviews

Laboratory

Technical rating

Lab Icon
See the test

Advice

Lorem ipsum dolor sit amet...

Read more

Characteristics

  • Panel power 425 Wp
  • Panel category Bifacial Half-Cut Panel
  • Efficiency 21.8%
  • Cell type N-Type TOPCon
  • Linear power output warranty 30 years
  • Standard warranty 12 years
  • Number of cells 108
  • Weight 23.7 kg
See all characteristics

General characteristics

Solar cells
N-Type TOPCon
Panel type
Framed
Model designation
JST-M10-M-54-MH-425W
Number of cells
108

Dimensions and weight

Dimension
Length 1722 mm
Width 1134 mm
Depth 30 mm
Weight
23.7 kg
Panel area
1.95 m²

Mechanical characteristics

Glass thickness
N/A
Frame type
Framed
Frame material
Anodized aluminum
Frame color
Silver
Junction box (diodes)
3 diodes
Output cable
Ø 4 mm² / 300 mm
Connector
MC4

Warranty

Material warranty
12 yrs
Linear power warranty
30 yrs
Power output
12 year(s); 87 %
30 years; 87 %

Higher lifetime electrical yield

First-year degradation
1 %
Linear degradation per year
N/A

ELECTRICAL DATA AT STC

Standard Test Conditions

Irradiance 1000W/m², cell temperature 25°C & AM1.5

Maximum output power (Pmax)
425 Wp
Maximum power voltage (Vmp)
32.18 V
Current at Pmax (Imp)
13.21 A
Open-circuit voltage (Voc)
38.28 V
Short-circuit current (Isc)
13.89 A
Module efficiency
21.8 %
Power tolerance
0/+5 W

ELECTRICAL DATA AT NOCT

Nominal Operating Cell Temperature:

Irradiance 800W/m², ambient 20°C, wind 1m/s

Maximum output power (Pmax)
320 W
Maximum power voltage (Vmp)
29.5 V
Current at Pmax (Imp)
10.85 A
Open-circuit voltage (Voc)
36.44 V
Short-circuit current (Isc)
11.42 A

TEMPERATURE COEFFICIENTS

NOCT
45 ± 2˚C
Temp. coeff. of Pmax
-0.3 %/˚C
Temp. coeff. of Voc
-0.25 %/˚C
Temp. coeff. of Isc
+0.05 %/˚C

MAXIMUM RATINGS

Maximum system voltage (IEC)
1500 V
Maximum system voltage (UL)
N/A
Max. series fuse
30 A
Operating temperature range
40 ˚C ~ 70 ˚C
Maximum front load (snow)
5400 Pa
Maximum back load (wind)
2400 Pa

Aucun documents disponible

No technical drawing available
