Solar Inverter On-grid 1 kW

0 0 reviews

General rating

0,0 /5

Latest review

L. Dupont

Review posted on 25 Juin 2025 by a user.

Unbeatable value for money

Quick installation, perfect design, discreet, easy to program, worked immediately. I recommend...

See all reviews
Laboratory
  • SOLAR INVERTER ON-GRID |
  • SOLAX POWER |
  • 1 kW |
  • Single-phase |
  • Maximum Input Voltage 1000 V |
  • Transformerless |
  • 2 MPPT |
  • IP65 |
  • Efficiency 98.1% |
  • L 280 mm, W 323 mm, D 444 mm |
  • 7.58 kg |
  • Warranty 6 years
Best price per Watt : 0.11 Per inverter : 111.11

Brand : SOLAX POWER

Globe #

Place Building C5, Huachuang Industrial Park, Shiji Town, Panyu District

user icon
location icon
calendar icon
installer icon
material icon
note icon
Free comments

Reply

Product image
Users 3218

Users (3218)

Installers 37

Installers (37)

Manufacturer 24
Distributors 56

Distributors (56)

Main suppliers

SOLARDROP
Payment WIMSE COIN, Credit card, Bank transfer
Per Watt : $0.12
View offer
WATT-U-NEED
Payment Credit card, Bank transfer
Per Watt : $0.14
View offer

Reviews

0 reviews

0,0/5
0
0
0
0
0
See all reviews

Laboratory

Technical rating

Lab Icon
See the test

Advice

Lorem ipsum dolor sit amet...

Read more

Characteristics

  • AC connection Single-phase
  • Output power 1000 W
  • Maximum panel power 390 Wp
  • Number of MPPT 2
  • Maximum efficiency 98.1%
  • Euro efficiency 98.2%
  • Maximum input voltage 1000 V
  • Standard warranty 6 years
See all characteristics
Product type
On-Grid Inverter
AC connection
Single-phase

Dimensions and weight

Dimension
Length 280 mm
Width 323 mm
Depth 444 mm
Weight
7.58 kg

Communication & Interface

Display interface
DISPLAY
Communication interface
4
5
System language
English

General characteristics

Reference
X1-1.5-S
Topology
1
Cooling method
1

Environment limit

Degree of protection
1
Operating temperature range
26 ℃ ~ 32 ℃
Maximum operation altitude
3000
Allowable relative humidity range
1 % - 99 %

Warranty

Standard warranty
6 years

INPUT (DC)

Maximum input voltage
1000 V
MPPT operating voltage range
20 V - 950 V
Maximum input current
15.5 A
Maximum DC short-circuit current
10 A
Independent MPPT inputs
2
Strings per MPPT input
1

OUTPUT (AC)

Rated output power
1000 W
Rated grid AC output current
A
Maximum AC output current
A
Nominal AC grid voltage
0Vac
Nominal grid frequency
0Hz
Total harmonic distortion, THDi at rated power
< %
Power factor at rated power
AC connection
Single-phase

EFFICIENCY

Maximum efficiency
98.1 %
Euro efficiency
98.2 %
MPPT efficiency
95.5 %

PROTECTION AND MONITORING

Over-voltage protection
No
Over-current protection
Yes
Over-temperature protection
Yes
RCD protection
No
Leakage current protection
Yes
DC reverse polarity protection
No
AC short-circuit current protection
Yes
Anti-islanding protection
Yes
Insulation resistance protection
Yes
Ground-fault current monitoring
Yes
DC injection monitoring
Yes
PID prevention
No
Over-voltage class of AC port
0
PDF

PRODUCT DATASHEET

Datasheet

PDF

PRODUCT USER MANUAL

Manual

Technical drawing

No packaging photos available
